Standard: SAE J20 R3
Applicable Liquid: Water, Alcohol,Antifreeze Fluid
Certificate: ISO/TS 16949:2009
Temperature: -40℃ ~ +150℃(-40°F ~ +300°F)
Application: Transporting oil to automatic transmission fluid
Tube: High quality EPDM rubber
Reinforcement: High tensile synthetic textile (PET)
Cover: High quality EPDM rubber
Features:
Good Heat Resistance
Good Ozone Resistance
Good Weather Resistance
| Type | Specification | length | W.P. | W.P. | B.P. | B.P. | |
| mm | inch | mm/roll | mpa | psi | Min.Mpa | Min.Psi | |
| SAE J20 R3-6 | 6 | 1/4” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-7.9 | 7.9 | 5/16” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-9.5 | 9.5 | 3/8” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-10 | 10 | 3/8” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-12.7 | 12.7 | 1/2” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-15.9 | 15.9 | 5/8” | 50 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-17.5 | 17.5 | 11/16” | 20 | 1.03 | 150 | 1.72 | 250 |
| SAE J20 R3-19 | 19 | 3/4” | 20 | 1.03 | 150 | 1.38 | 200 |
| SAE J20 R3-25.4 | 25.4 | 1” | 20 | 1.03 | 150 | 1.2 | 175 |
